C2073 Pinout :
1. Base
2. Collector
3. Emitter
4. Collector ( Case )
Absolute maximum ratings ( Ta=25?C )
1. Collector to Base Voltage : Vcbo = 150 V
2. Collector to Emitter Voltage : Vceo = 150 V
3. Emitter to Base Voltage : Vebo = 5.0 V
4. Collector Current : Ic = 1.5 A
5. Total Dissipation : Pc = 25 W
6. Junction Temperature : Tj = 150?C
7. Storage Temperatue : Tsg = -55 ~ 150?C
