? USB Port Connection
The USB port connection is a USB mini-B connector. Connect the PICkit 2 to the PC using
the supplied USB cable.
? Status LEDs
The Status LEDs indicate the status of the PICkit 2.
1. Power (green) Power is applied to the PICkit 2 via the USB port.
2. Target (yellow) ? The PICkit 2 is powering the target device.
3. Busy (red) The PICkit 2 is busy with a function in progress, such as
? Push Button
The push button may be used to initiate the Write Device programming function when
Programmer>Write on PICkit Button is checked on the PICkit 2 Programmer
The push button may also be used to put the PICkit 2 unit operating system firmware
into Bootloader mode. For more information on this feature
? Programming Connector
The programming connector is a 6-pin header (0.100? spacing) that connects to the target device.
PICKIT2 PIC Kit2 Simulator PICKit 2 rogrammer Emluator USB
PIC or DSPIC : Nex Electronic
? Support for PICKIT2 IC, can be viewed MPLAB IDE v8.56 software
? pen the software, configure-> select device PICKIT2 support in front of the green light
? PICKIT2 online programming and debugging Microchip
? PICKIT2 is inexpensive PIC development tools.
