Package- 4-SIP
Reverse voltage-1000V (1kV)
Forward voltage- 1V
Speed-Standard Recovery >500ns, > 200mA (Io)
From Shelfkey
Sale!
KBL10 RECTIFIER BRIDGE 4A 1000V (Pack of 5)
₹290.00 Original price was: ₹290.00.₹189.00Current price is: ₹189.00.
Nex Electronic: Simple Solution For Complex Connections
QUICK VIEW:
Specifications
Attribute Value
Bridge Type Single Phase
Peak Average Forward Current 4A
Peak Reverse Repetitive Voltage 1000V
Mounting Type Through Hole
Package Type KBL
Pin Count 4
Configuration Single
Peak Non-Repetitive Forward Surge Current 200A
Maximum Operating Temperature 150 ?C
Minimum Operating Temperature -50 ?C
Peak Forward Voltage 1.1V
Peak Reverse Current 1mA
Length 19.5mm
Width 6.5mm
Height 16.3mm
Dimensions 19.5 x 6.5 x 16.3mm
🔥 Buy More Save More!
Quantity | 1+ | 6+ | 11+ | 21+ | 50+ |
---|---|---|---|---|---|
Price | ₹189.00 | ₹179.55 | ₹170.10 | ₹160.65 | ₹151.20 |
Estimated delivery dates: Oct 3, 2025 - Oct 8, 2025
Only logged in customers who have purchased this product may leave a review.
