1N5819 DIODE (Pack of 5)
Original price was: ₹35.00.₹21.00Current price is: ₹21.00.
Nex Electronic: Simple Solution For Complex Connections
QUICK VIEW:
Product description Below
🔥 Buy More Save More!
| Quantity | 1+ | 6+ | 11+ | 21+ | 50+ |
|---|---|---|---|---|---|
| Price | ₹21.00 | ₹19.95 | ₹18.90 | ₹17.85 | ₹16.80 |
Estimated delivery dates: Jul 18, 2025 - Jul 23, 2025
Mechanical Characteristics:-
? Case: Epoxy, Molded
? Weight: 0.4 Gram (Approximately)
? Finish: All External Surfaces Corrosion Resistant and Terminal Leads are Readily Solderable
? Lead Temperature for Soldering Purposes: 260?C Max for 10 Seconds
? Polarity: Cathode Indicated by Polarity Band
? ESD Ratings: Machine Model = C (>400 V) Human Body Model = 3B (>8000 V)
Specification:-
Symbol Parameter Value Units
VRRM Peak Repetitive Reverse Voltage 40 V
VRWM Working Peak Reverse Voltage 40 V
VR DC Blocking Voltage 40 V
VR(RMS) RMS Reverse Voltage 28 V
VRSM Non?Repetitive Peak Reverse Voltage 48 V
IO Average Rectified Output Current 1 A
IFSM Non-Repetitive Peak Forward Surge Current 25 A
TJ Operating Junction Temperature Range ? 65 to 125 ?C
Tstg Storage Temperature Range ? 65 to 150 ?C
